360 Magneto Optical System Elight Shr RF OPT Hair Removal 755 Nm
Picosecond Laser Tattoo Removal Machine
Theory
E-light takes strong pulse IPL and bipolar radio frequency
electromagnetic wave with special width-spectrum, selectively acts
on target texture, to do skin rejuvenation, freckle removal, hair
removal, wrinkle removal effectively. On treatment if 5 to 10 times
than traditional photon therapy.
Application for 3 handles:
360 magneto -optic SHR
1. Therapy acne
2. Reduction of vascular lesions
3. Reduction of pigmented lesions
4. Skin rejuvenation
5. Permanent hair removal
6. Wrinkle removal
RF
1. Skin lifting, tightening, and whitening
2. New collagen stimulation and production
3. Removes fine lines and wrinkles
4. Facial remodeling and body contouring
5. Visibly minimize pores
6. Circumference and cellulite reduction
7. Body Shaping areas: abdomen, buttocks, thighs, neck, upper arms.
Picosecond Laser
1. 1064nm Wavelength: Remove black and dark blue tattoo pigments,
such as tattoos, eyebrows, dark color around the eyes, freckle, age
spot etc.
2. 532nm Wavelength: Remove red and brown tattoos and red mark.
3. Black Doll ( 1320nm ) : Skin Rejuvenation , Skin tightening ,
Skin Whitening.
4.755nm for large area treament, best effect for Chloasma than
other laser
ents removal. There are 3 probes with different wavelength
(1064nm,532nm,1320nm)for treating different items.
Advange
1. Magneto-optic Handle: No need replace filter, the machine
automatically select the wavelength requiredand permanent hair
removal.
2. Picosecond Laser Handle: quick and easy non-surgical,
non-invasive laser skin treatment for the body including chest or
decollete, face, hands, legs, and more.
Technical Parameter
| IPL system |
| Handle mode | Filters handle, sapphire handle and high power handle |
| Spot size: | 8*40mm2 or 15*50mm2 |
| Energy density: | 1-20J/cm2 |
| Pulse frequency: | 1~4S, adjustable |
| Pulse number: | 1~6, adjustable |
| Pulse space: | 05~99ms, adjustable |
| Sub-pulse width: | 0.1~9.9ms, adjustable |
| Handle cooling temperature: | -10°C~0°C, adjustable |
| Power: | 2000W (Elight ) ; 1000W (Laser) |
| Lamp longevity: | 200,000shots (IPL) 1,000,000shots(Laser) |
| Language | English,Spanish,France .Italian ,German,Chinese |
| RF system |
| RF frequency | 10MHZ |
| Energy density: | 1-20J/cm2 |
| Output mode: | Bipolar |
| Energy | 2~300J, adjustable |
| Handle cooling temperature: | -10°C~0°C, adjustable |
| Cooling system: | Air + Water + Semi-conductor cooling |
| Screen | 8.4 inch true color touch screen |
| Power supply | 110/240V+10% 60/50Hz |
| Size | 75*48*120cm |
| Weight | 69kg |
| Picosecond laser | |
| Laser wavelength | 1064nm/755nm/532nm/1320nm |
| Pulse Energy | 2000MJ |
| Width of pulse | 10-20ns |
| Frequency | 1~10Hz |
| Spot Size | 2~10mm |
| Cooling system | Radiator, air+water-cooled |
| Light source | 220V/110v 50Hz/60Hz |
Light energy performance
1. Single pulse energy: Jm ≥ 2000mj
2. Laser output instability: S ≤ ± 15%
3. Laser output energy reproducibility: Rj <10%
4. Output energy and energy display error: ≤ ± 20%
5. Surgery spot diameter: 1-4nm range continuously adjustable
6. Spot positioning focusing accuracy: the error ≤ ± 0.5mm
7. Multi-joint light guide arm adjustment range: ≥ 45 ° in the
horizontal plane, the vertical height from the ground between 60cm
- 80cm.
