Baolai L3 detachable aluminum alloy LED handpiece is the first
invention and No.1 durable in the field of ultrasonic scaler all over the world, which
obtains 15 patents. Its advantages as following:
1. Better heat dispersion. Handpiece shell is made of aluminum alloy in order to solve
thermal dissipation problem, and all radiation fins are made of
aluminum alloy materials. The user feels hot when holding plastic
handpiece mainly because plastic does not disperse heat well.
2. Aluminum alloy strength is much better than plastic and it will not crack, while plastic is easy to crack after repeating autoclave.
3. No yellowing.No deformation.
4. Compatible with EMS Minimaster & Piezon 700 scaler.
5. It and its spare parts can be autoclaved together or separately, but other brands' LED lamp and light guide can't be autoclaved separately.
6. Use life of LED lamp and light guide are longer than EMS according to repeated testing
in our lab.
7. LED color temperature: 3000K-3200K, warm white light. Dentist is not easy to feel tired when operation. White light is optional.
Now other Chinese competitors are following us to develop aluminum
alloy handpieces or copy ours. But our aluminum alloy handpiece is No.1 durable in the world.
| Adapter Input | 100-240V~ 50/60Hz 0.7A-0.4A |
| Main unit input | 30V 1.2A |
| Main unit fuse | 250V/T 1.6AL |
| Output power | 3W~ 20W |
| Output primary tip vibration excursion | ≤200μm |
| Output tip vibration frequency | 28kHz±3kHz |
| Output half-excursion force | <2N |
| Water pressure | 0.1MPa~0.5MPa (1bar~5bar) |
| Weight of main unit | 0.55kg |
| Weight of adapter | 0.34kg |
| Operating mode | Continuous operation |
| Electric shock protection type | Class II |
| Classification 93/42/EEC | Class II a |
| Degree of protection against electric shock | B |
| Degree of protection against harmful ingress of water | Ordinary equipment(IPX0), Foot switch(IPX1) |
| Degree of safety of application in the presence of a Flammable
Anesthetic Mixture with air or with Oxygen or Nitrous Oxide | Equipment not suitable for being used in the presence of a
flammable anesthetic mixture with air or with oxygen or nitrous
oxide |
