WD3 Multi-Functional Orthodontic Spot Welder Foot Operated
1. technique parameter
1. Power supply: AC 110V, 60 Hz
AC 120V, 60 Hz
AC 220V, 50 Hz
AC 230V, 50 Hz
AC 240V, 50 Hz
2. Power: maximum instantaneous current 20A
3. Transformer output power: 2000W, output voltage: 5V
4. Incorrect operation alarm: when operation condition don’t accord
with SET mode, the display shows Error beep.
5. Security type: belong to classⅠ, type B
6. Transformer overheating protection: 85°C
7. Energy regulation: Spot welding (dxx) 1~30
Braze welding (q_x) 1~9
Heat treatment (h_x) 1~9
8. Dimensions of weldment: Diameter 0.2mm~1.8mm stainless steel wire
9. Fuse: Diameter 5×20mm, 20A
10. Environment conditions: temperature 5°C~40°C, Relative humidity ≤80%
11. Storage condition: temperature -10°C~55°C, Relative humidity ≤80%
2. Applicant
multi-functional spot welding used for welding stainless steel
wire, stainless steel sheet, also be used for heat treatment of
arch wire materials forming in dental orthodontics and treatment.
3.characteristics
(1). Adopt microprocessor control system, reliable quality, and
high control precision.
(2). Adopt LCD displays functional mode and power parameter,
through membrane button to adjust the parameter, it’s convenient
and concise.
(3). Good in safety feature; it has overheating protection system,
(4). With the welding parameters memory function
(5). Welding electrodes can be chosen with different combination,
it’s suitable for the different weldments.
(6). It has various functions as spot welding, braze welding and
heat treatment.
(7). HL-WD III with function clamps operation in heart treatment,
and arch wire forming.
4. Packing list:
| No. | Name | Quantity |
| 1 | Main machine | 1 |
| 2 | Power cord | 1 |
| 3 | Foot switch | 1 |
| 4 | Fuse 20A | 1 |
| 5 | Function clamps | 2 |
| 6 | State block | 1 |
| 7 | Heat treatment clamp holder | 1 |
| 8 | Certificate | 1 |
| 9 | Warranty card | 1 |
| 10 | Manual | 1 |
