BM-868 Wi-Fi Skin/Scalp Analyzer With 8 Inch Monitor
Characteristic
1. High resolution Scalp analyzer with 8inch LCD screen
2. Analyzer with 50times or 200 times lens, sensitive scalp also
can be inspected.
3. With high resolution, high performance High sensitivity and high
quality.
4. The five control buttons: freeze/save, previous image, next
image, one/four/nine images switches and delete image, single
button control function, more convenient to use
5. full images display, two kinds of capture angles, display the clear
images.
6. Can match with our company’s multifunctional 8inch LCD screen,
12.1inch LCD screen and 15inch LCD screen and can match with common
specification screens through docking station.
7. Choose our multifunctional LCD screen and WI-FI docking station
can transmit the images to mobile phone, Tablet PC and Windows computer at the same time.
8. Comes with a USB flash disk can save 9999pcs images.
9. It can record the video by the remote control, size of memory
according the USB flash disk, the picture and the video can be
saved to USB flash disk permanent.
10. Comes with analyzer’s holder, more convenient to use.
11. Optional WI-FI device can transmit the analyzer’s images to mobile phone, Tablet PC and computer at the same time.
8 inch LCD monitor specification
1. LCD Size : 8.0inch (Diagonal)
2. Driver element: a-Si TFT active matrix
3. Resolution: 800*3(RGB)*600
4. 4,Display mode: Normally White, Tran missive
5. Dot pitch: 0.0675(W)*0.2025(H)mm
6. Active area : 162.0(W)*121.5(H)mm
7. 7,Module size: 183.0(W)*141.0(H)*6.3(D)mm
8. 8,Surface treatment: Anti-Glare
9. Color arrangement: RGB-stripe
10. Interface: Digital
11. 11: Backlight Power consumption:1.782W(TYP.)
12. Panel power consumption :0.356W(TYP)
LCD Size | 8.0inch (Diagonal) |
Driver element | a-Si TFT active matrix |
Resolution | 800*3(RGB)*600 |
Display mode | Normally White, Tran missive |
Dot pitch | 0.0675(W)*0.2025(H)mm |
Active area | 162.0(W)*121.5(H)mm |
Module size | 183.0(W)*141.0(H)*6.3(D)mm |
Surface treatment | Anti-Glare |
Color arrangement | RGB-stripe |
Interface | Digital |
Backlight Power consumption | 1.782W(TYP.) |
Panel power consumption | 0.356W(TYP) |
1. Scalp analyzer | 1 pcs |
2.8inch LCD screen | 1 pcs |
3.AV cable | 1 pcs |
4.USB flash disk | 1 pcs |
5.Remote control | 1pcs |
6.DC-12V adaptor | 1 pcs |
7 .VGA cable | 1 pcs |
8 .Holder | 1 pcs |
9 .USB cable | 1 pcs |
10 .Handbag | 1 pcs |
11.CD disk | 1 pcs |
12. 8PIN cable | 1 pcs |
13. Scalp analyzer’s lens | 1 pcs |
